Cat5 Cat5e 8 Pin Led Connector RJ45 Magjack Network Connector Female PCB Connector RJ45 Modular Jack
Cat5 Cat5e 8 Pin Led Connector RJ45 Magjack Network Connector Female PCB Connector RJ45 Modular Jack
Cat5 Cat5e 8 Pin Led Connector RJ45 Magjack Network Connector Female PCB Connector RJ45 Modular Jack
Cat5 Cat5e 8 Pin Led Connector RJ45 Magjack Network Connector Female PCB Connector RJ45 Modular Jack
Cat5 Cat5e 8 Pin Led Connector RJ45 Magjack Network Connector Female PCB Connector RJ45 Modular Jack
1 / 5
Cat5 Cat5e 8 Pin Led Connector RJ45 Magjack Network Connector Female PCB Connector RJ45 Modular Jack
Cat5 Cat5e 8 Pin Led Connector RJ45 Magjack Network Connector Female PCB Connector RJ45 Modular Jack
Cat5 Cat5e 8 Pin Led Connector RJ45 Magjack Network Connector Female PCB Connector RJ45 Modular Jack
Cat5 Cat5e 8 Pin Led Connector RJ45 Magjack Network Connector Female PCB Connector RJ45 Modular Jack
Cat5 Cat5e 8 Pin Led Connector RJ45 Magjack Network Connector Female PCB Connector RJ45 Modular Jack

Cat5 Cat5e 8 Pin Led Connector RJ45 Magjack Network Connector Female PCB Connector RJ45 Modular Jack

Send Inquiry

Product Description

Network Connector Diagram
Specification
Item Value
Model Number Network connector
Part Status Active
Connector Type RJ45
Applications-Lan Ethernet(PoE/Non_PoE)
Speed 10/100/1000/2.5G/5G/10G Base-T, AutoMDIX
Mounting Type Through Hole
Orientation 90° Angle (Right)
Termination Solder
Contact Finish Thickness 6.00µin (0.152µm)
LED Color Yellow/Green, Green/Yellow, Green&Yellow/Green&Yellow
Number of Cores per Jack 4/6/8/12
Shielding Shielded, Emi Finger
Number of Ports Multi-port rj45, stacked rj45, low profile rj45 , vertical rj45 , smt rj45
Features Board Guide
Tab Direction Down/Up
Contact Finish Gold
Configuration RX/TX T,C
Turns Ratio RX/TX 1CT:1CT
Operating Temperature 0°C ~ 70°C/-40°C ~ +85°C
Connector Drawing Details
Connector Measurements
Product Layout
Internal Schematic
Product Diagram Details
Product Drawing Details
PCB Layout Design
Product Pin Setup
We are a specialized manufacturer of magnetic telecom and networking components, certified by ISO9001:2000, ROHS, REACH, CE and UL. We own advanced manufacturing facilities and test equipment. We provide professional, complete solutions for magnetic components as well as robust technical support. Our products are widely used in networking and communication equipment such as HUBs, PC cards, Switches, Routers, PC Mainboards, SDH, PDH, IP Phones, and xDSL modems.
Main Products
  • 10/100/1000M/2.5G/5G/10G LAN pulse transformer and filter
  • RJ45 connector with 10/100/1000M/2.5G/5G/10G magnetic
  • T1/E1, T3/DS3/E3/STS-1 interface line transformer
  • ISDN, HDSL, ADSL and VDSL interface line transformer and splitter
FAQ
Are you a manufacturer or trade company?
We are a manufacturer specialized in RJ45 connectors and LAN Transformers for more than 23 years.
Can I get some samples?
Yes, 3-5 pcs free samples are available for your testing. Small batch orders are also acceptable.
Is OEM service available?
Yes. We have rich experience and complete capability to turn your designs and ideas into real products. We can also laser print your brand on the products.
How about the lead time?
We have a highly professional team working to high standards. Usually, we can ship orders within 30 days. For specific order detail updates, please contact us.
What standards and certifications do your network components comply with?
Our manufacturing processes and magnetic components are fully compliant and certified under ISO9001:2000, RoHS, REACH, CE, and UL standards.
What network speeds do your integrated RJ45 connectors support?
Our products support speeds ranging from 10/100/1000M up to high-speed 2.5G, 5G, and 10G Base-T Ethernet applications.
