200GBASE-SR4 Optical Transceiver Module MTP/MPO-12 MMF Multimode 850nm 200G QSFP56 100m

Product Description

200GBASE-SR4 Optical Transceiver Module MTP/MPO-12 MMF Multimode 850nm 200G QSFP56 100m
Products Description
Item Fiber Optical Modules
Part Status Active
Form Factor QSFP56
Max Data Rate 200Gbps
Max Cable Distance 70m@OM3/100m@OM4
Wavelength 850nm
Connector MTP/MPO-12 UPC
Media MMF
Optical Component VCSEL/PIN
TX Power -3~3dBm
Receiver Sensitivity -6.5dBm
Powerbudget 3.5dB
Receiver Overload 5dBm
Power Consumption ≤5W
Extinction Ratio 3dB
DDM/DOM DDM Supported
Commercial Temperature Range 0 to 70°C (32 to 158°F)
Warranty 5 Years
Sample Available
Protocols 200G Ethernet, Data centers Interconnect, High performance computing
VIEW OUR SOLUTION
We draw on over 10 years of experience in chips and modules to integrate fast speeds, small size, power savings, and high performance in every module. We provide a full series of optical modules for fixed access, wireless access, carrier Ethernet, wavelength division multiplexing (WDM), and data communication networks.
Solution details
Solution details
Solution details
Product variety
Module mapping list
Optics specifications
Details of transceiver
Details of transceiver back
Related Products SFP Cage
SFP Cage details
Why Choose Us
Qualification certification 1
Qualification certification 2
Quality control process
Manufacturing line
Company Profile
We are a specialized manufacturer of magnetic telecom and networking components, certificated by ISO9001:2000, ROSH, REACH, CE and UL, owning advanced manufacturing facilities and test equipments imported from abroad.

Established in 1997, we currently have around 2,000 staff members. With an abundant productive capacity of 3,000K units per month, we are able to deliver products within a short time.

Moreover, we provide a full series of optical modules for fixed access, wireless access, carrier Ethernet, wavelength division multiplexing (WDM), and data communication networks. The range also offers high-speed optical interconnection solutions for cloud computing and ultra-broadband networks. Using the latest optoelectronics technologies, we develop, manufacture, and sell high-performance products worldwide.
Production facility lab
Testing equipment
FAQ
1. Are you a factory or a trading company?
We are a specialized manufacturer of magnetic telecom and networking components, including RJ45 connectors, LAN transformers, RJ11 connectors, SFP modules, and more.
2. Can I get a sample before mass production?
Yes, we can offer you free samples to test quality, but shipping costs will be your responsibility.
3. What is your delivery time?
Stock items are ready to ship immediately, while mass production typically takes 15 to 30 days.
4. What after-service can you offer?
We provide a one-year guarantee period along with 24-hour online technical support.
5. Can you accept OEM/ODM orders?
Yes, please submit an inquiry so we can discuss the details of your project requirements.
6. What is your advantage?
We bring over 19 years of manufacturing experience and have partnered with major global technology leaders for many years.
