OptiLinker
OptiLinker
| Item | RJ45 Female Connector |
| Part Number | LPJU4111AONL |
| Alternative Part Number | 08C2-1X1T-36 |
| Part Status | Active |
| Connector Type | Jack |
| Number of Positions/Contacts | 8p8c (RJ45, Ethernet) |
| Application-Lan | Ethernet (Non PoE) |
| Number of Ports | 1x1 Port |
| Speed | 10/100 Base-T |
| Latch | Up |
| Cores per Port | 4 |
| Orientation | 90° Angle (Right) |
| PCB Mount Angle | SIDE ENTRY |
| Shield EMI Tabs | With |
| LED Option | Green/Yellow |
| PCB Material | FR4 |
| PCB Retaining Post | T POST |
| Temperature Range | 0℃ TO 70℃ |
| Bst Circuit | Yes |
| AutomDX | YES |
| Contact Mating Area Plating | GOLD 6u"/15u"/30u" |
| Turns Ratio RX/TX | 1CT:1CT |
| Configuration RX/TX | T,C |
As a specialized manufacturer of magnetic telecom and networking components, our production facility is certified by ISO9001:2000, ROHS, REACH, CE and UL. We utilize advanced manufacturing facilities and testing equipment to ensure the highest quality standards. Established with decades of experience, we maintain a robust workforce and a monthly productive capacity of 3000K, ensuring rapid delivery times.
Main Product Categories:
Our solutions are widely integrated into networking and communication equipment including HUBs, PC cards, Switches, Routers, PC Mainboards, SDH, PDH, IP Phones, and xDSL modems. We serve clients across more than 30 countries and regions globally, including Germany, France, England, USA, Singapore, Korea, Canada, and Japan.
